UT612 USB Interface 20000 Counts Inductance Frequency Test Deviation Ratio Measurement LCR Meters with box

UT612 USB Interface 20000 Counts Inductance Frequency Test Deviation Ratio Measurement LCR Meters with box

Display Count: 20000
D/Q Display Count: 2000
D/Q Resolution: 0.001
Auto Range: √
Real-Time Display Test Frequency: √
Measurement Mode: Series/Parallel
Auto Power Off: √
Low Battery Indication: ≤6.8V
Data Hold: √
Relative Mode: √
USB Interface: √
USB Interface/PC Data Records: 60000
LCD Backlight: √
Analogue Bar Graph: 26
Deviation Ratio Measurement: √
Comparsion Function: √
Calibration Function: √
Output Impedance: 120?
Auto LCR Smart Check and Measurement: √

Model: UT612
Inductance (H): 20uH?2000H ±(0.5%+5)
Capacitance (F): 200pF?20mF ±(0.5%+5)
Resistance (?): 20??200M? ±(0.3%+5)
Test Frequency (Hz): 100Hz/120Hz/1KHz/10KHz/100KHz
Operational Voltage: 0.6Vrms
Test Parameters: L/C/R/DCR/Q/D/?/ESR

General Characteristic:
Product Net Weight: 374g
Product Size: 96 * 193 * 47mm
Power: 9V Battery?6F22) or USB(not included)
LCD Size: 40 * 63mm
Product Colour: Red and Grey
Package Size: 29 * 22.5 * 7cm / 11.4 * 8.8 *2.7in
Package Weight: 1157g / 2.5lb

Package:

100% Brand new

1 * UNI-T UT612 LCR Meter
1 * SMD Test Clamp
1 * USB Interface Cable
1 * Multi-Purpose Socket
1 * PC Software CD
1 * English Manual
